Recently I needed to customize the behavior of one router allowing it to send custom heartbeat messages to a cloud service.

At glance, this sounds like a trivial task with obvious possible solutions:

  • Use the router firmware’s default functionality

    :x: Stop factor:

    • I need to have full control over the format and contents of the message

    • the router is running a custom firmware flashed: Tomato Firmware 1.28.0000 MIPSR2-140 K26 Mini with a tiny Linux distribution

  • Then just use the cURL / wget / …

    :x: Stop factor:

    There’s no cURL/wget in that Linux installment and there’s even no easy way to install some because there’s no package manager due to limited ROM size restrictions.

  • That Linux has netcat so use it to manually format the HTTP message

    :x: Stop factor: Remote service is accessible only via HTTPS and even though I can configure it to accept unencrypted HTTP too, I don’t want to. And netcat can’t deal with SSL encryption.

  • Looks like a hopeless situation :scream:

    :heavy_check_mark: Solution recipe from Ron: Real men know the answer

Luckily, searching this Linux distro for all available commands ended with success: it has openssl :wink:.

A curious fact: its ‘super power’ for sending HTTPS requests is not widely ‘googlable’ over the Internet, that’s why I decided to write it down as a reminder for myself as well as others:

openssl s_client -crlf -quiet -connect example.com:443 <<EOF
POST /heartbeat HTTP/1.1
Host: example.com
X-ApiKey: 666
Content-Type: text/plain
Content-Length: 19
Connection: Close

$(date +'%Y-%m-%d %H:%M:%S')
EOF

Here we’re sending a manually composed HTTP message over the SSL to the example.com host with some example payload.

Important note:

openssl s_client is mostly a debug tool so use it wisely and ideally strive for another solution that would follow the expected behavior for invalid certificates, excerpt from the docs:

s_client can be used to debug SSL servers.

…

The s_client utility is a test tool and is designed to continue the handshake after any certificate verification errors. As a result it will accept any certificate chain (trusted or not) sent by the peer. None test applications should not do this as it makes them vulnerable to a MITM attack. This behaviour can be changed by with the -verify_return_error option: any verify errors are then returned aborting the handshake.

:v:
